Lentil Robot Palletizer line for Egypt

Infusion bag packing line

Name	Infusion bag packing line
Filling volume	300-5000ml
Filling Heads	1—12
Capacity	2000-3500 bottles/hour
Control system	PLC+ Touch screen
Precision	±0.5-1.0%
Bottle height	100-250 mm (adjustable)
Voltage	AC220V or AC 380V
Power	2.0-3.5Kw.
Pneumatic	0.35cbm/min, 0.6-0.8Mpa
Dimension	L550*W85*H190cm
G.W.	900-1200Kg.
Auxilary equipments	Auto bottles feeder, auto capping machine, auto induction sealing machine, auto labelling machine, shrink labelling machine, ink-jet printer, auto carton packing machine,etc.
Function	This automatic filling machine, adopts plunger pump filling, Equiped with PLC and touch screen, easy to operate. Main pneumatic parts and the electronics are famous brand from Japan or German. The body and the parts contacting with product is stainless steel, clean and sanitary comply with GMP standard. The filling volume and speed can be adjusted easily, and filling nozzles could be changed according to actual needs. This filling line can be used to fill various liquid products of medicines, foods, drinks, chemicals, detergents, pesticide, etc. e.x. shampoo, detergent, lotion, juice, wine, vinegar, etc.

Product overview:

Automatic automatic bottle filling the product, high filling accuracy, according to different specifications of bottles can be arbitrarily adjusted filling volume and bottle size, can be equipped with automatic assembly line. The lotion, liquid care, oral liquid, hair care liquid, liquid soap, lotions, disinfectant, liquid foundation, antifreeze, shampoo, wash liquid filling eye drops, nutrient solution, injection, pesticide, medicine, detergent, shower gel, perfume, edible oil, lubricating oil and special industry.

Widely used in chemical, oil and other industries, can be different filling of high viscosity fluid. The machine is compact and reasonable in design, simple and beautiful appearance, easy to adjust filling volume.

Product features:

The 1 Principle: the filling machine is a semi automatic piston filling machine. To extract and control of material flow with one-way valve type material through the cylinder drives a piston, control the stroke of the cylinder with the magnetic reed switch, can adjust the filling volume.

2 properties: semi automatic piston type single head liquid filling machine produced by our company is based on the company's production of filling machine series, the introduction of foreign advanced filling machine technology, to carry out the reform and innovation further, its structure is simple and reasonable, high precision, the operation is more convenient, is your ideal choice for high filling service.

3 is made of 316L stainless steel

4 pneumatic components are used in Germany Pneumatic components, PLC automatic control system

5.The 5 seal with silicone rubber (abrasion resistant, high temperature resistant, acid and alkali resistance, corrosion resistant), fluorine rubber (abrasion resistance, strong acid, strong corrosion)

6 pneumatic device, safety is better.

7 the lotion, liquid care, oral liquid, hair care liquid, liquid soap, lotions, disinfectant, liquid foundation, antifreeze, shampoo, washing liquid filling eye drops, nutrient solution, injection, pesticide, medicine, detergent, shower gel, perfume, edible oil, lubricating oil and special industry

Automatic automatic bottle filling 8 this product, high filling accuracy, according to different specifications of bottles can be arbitrarily adjusted filling volume and bottle size, can be equipped with automatic assembly line

Technical parameters:

Power 220/110V 50/60Hz

The filling speed of 30-60 bottles / minute

Filling accuracy ≤ ± 1

Pressure 0.40.6MPa

Current 3A

Power 300W

Optional models 25-250ml 50-500ml 100-1000ml 250-2500ml
